DATA SHEET ? SKY13335-381LF SPDT SWITCH
2.00 ± 0.05 (See Note 3)
4.00
? 1.00 Min.
? 1.50 + 0.1/–0.0
0.30 ± 0.05
4.00 (See Note 1)
1.75 ± 0.10
A
Pin #1
R0.20 Max.
Bo
A
Ko
A
Notes:
1. 10 sprocket hole pitch cumulative tolerance ± 0.2.
2. Chambre in compliance with EIA 481.
3. Pocket position relative to sprocket hole measured
as true position of pocket, not pocket hole.
4. Carrier tape: black conductive polycarbonate or polystyrene.
5. Cover tape material: transparent conductive PSA.
6. Cover tape size: 9.3mm width.
7. All measurements are in millimeters.
Ao
R0.3 Typ.
Ao = 1.70
Bo = 2.20
Ko = 0.55
S1723
Figure 12. SKY13335-381LF Tape and Reel Dimensions
Skyworks Solutions, Inc. ? Phone [781] 376-3000 ? Fax [781] 376-3100 ? sales@skyworksinc.com ? www.skyworksinc.com
8
October 1, 2009 ? Skyworks Proprietary Information ? Products and Product Information are Subject to Change Without Notice ? 201093C
